Featured Products
|
|
 |
DN-400 Series
DeviceNet 4-in, 4-out 24V Discrete I/O
The DN-400 provides a DeviceNet interface to control and monitor 4 general
I/O points and includes two extra inputs to monitor on-board and external 24 VDC
auxiliary power. Available in two sizes, the standard sized DN-TC400 (60mm x
68mm) or the reduced sized DN-TC400-0.5 (38.1mm x 63.5mm), two connector
options (shrouded or open headers), and multiple power configurations the DN-400
fits neatly into any DeviceNet I/O application.
|
|
 |
DN-410 Series
DeviceNet Serial ASCII I/O
Huron Net Works’ DN-410 series products provide a low cost solution
for connecting to serial data over DeviceNet. The DN-410 uses Huron Net
Works’ DeviceNet Serial Link Interface Protocol (DN-SLIP) to allow
point-to-point communication between serial I/O and DeviceNet.
Conveniently configurable using any EDS capable configuration tool and
available in two form factors, the DN-410 series fits neatly into any
application.
|
|
|
|
PDP-400
New!
Profibus DP-V0 4-in, 4-out 24V Discrete I/O
The PDP-400 provides an Profibus DP-V0 interface to control and monitor 4 general I/O points.
Designed to be a drop in replacement for our existing DN-400
and EIP-400
boards, this low-cost product will provide a quick and simple
Profibus interface for your I/O.
|
|
 |
PMV08 NEW!
8 Port Pneumatic Manifold Valve with 24V Control
The PMV08 Pneumatic Manifold Valve converts a 24V electrical command
signal to a pneumatic signal. Typically used in paint booths, the PMV08
is perfect for applications which require pneumatic control to eliminate
fire and explosion hazard from the manufacturing environment.
Offering eight electronically controlled solenoid valves and an eight
port manifold assembly, the PMV08 installs conveniently into a standard
3U subrack. |
|
 |
DN-HV500 New!
DeviceNet Interface for Vishay High Tension System
The DN-HV500 is a compact low cost DeviceNet network interface to the
Vishay High Tension System controller. This module replaces
expensive modular or rack I/O subsystems with a solution optimized for
the Vishay system. |
|
 |
Huron Net
Works’ offers a variety of low cost custom physical media components
ranging from a DeviceNet open-style connector tap to custom mini
connector assemblies and labeling.
|
|
 |
DN-Custom
DeviceNet Made to Order I/O
Huron Net Works specializes in custom DeviceNet I/O. We can bring
DeviceNet capability, optimized for your specific requirements, to your
products. We have provided instant network-capable product lines for
major industrial control suppliers providing systems for material
handling, material pull, automatic paint spray, robotic welding, motor
control, and quality assurance. We will support your engineering
and production teams from concept through production.
|
|
|
Additional Products
|
|
 |
CDMEM NEW!
DeviceNet Master Emulator
CDMEM is a low cost DeviceNet development software tool that is designed to
run on our newest development platform, the DeviceGate.
This software is loaded onto the DeviceGate and is easy to reach from any type
of computer that can utilize telnet connections. |
|
 |
DeviceGate NEW!
Ethernet-to-DeviceNet Interface
The DeviceGate DN-E100 is a low-cost Ethernet-to-DeviceNet interface
containing an integrated TCP/IP stack with a web server. A DeviceNet
emulator application (including all of the capabilities of our already
popular DN-MEM) is included standard with the DN-E100 and can be
conveniently controlled using any standard web browser. |
|
 |
DN-100 Series
DeviceNet 1-in, 1-out 24V Discrete I/O
The DeviceNet DN-100 series provides a single digital input and a
single digital output in a sealed tubular package (166mm x 22.4 mm dia.)
This device provides an ideal network attachment solution for a variety of
non-networked sensor/actuator combinations.
|
|
 |
DN-1600
DeviceNet 16-in, 16-out 24V Discrete I/O
The DN-1600 is a compact I/O module that provides direct connection of
sensors, limit switches, and other discrete input devices. The DN-1600 also
provides output drivers for relays, solenoids, lamps and other discrete
output devices. Connections are made through standard plug-in screw
terminals. The module is housed in a DIN rail mounting shell.
|
|
 |
DN-500
DeviceNet 5-in, 5-out Discrete I/O for use in Lighted Push Button Pendant applications
The DN-500 module provides a DeviceNet connection to five 5VDC
general purpose inputs and five bus voltage 40mA outputs with overload
protected and faults signals. The DN-500 offers five pluggable Square-D
sockets (PN: ZB6Y010) ideal for any lighted push button panel or pendant
application. Also provided are five screw terminal connectors in
parallel with the sockets to allow for alternative configurations or the
addition of alternative push button vendors' products.
|
|
 |
DN-A101
DeviceNet Analog current loop in, 120 VAC out
The DeviceNet DN-A101 combines a 4-20ma input and an AC output in a
rugged aluminum enclosure. The input, with 8-bit resolution, can be used
to sense any analog value (e.g. current, voltage, temperature, pressure,
or flow) from any 4-20ma transmitter.
|
|
 |
DN-A102
DeviceNet Pneumatic Valve (dense pack) Interface Module
The DN-A102 is a DeviceNet interface module for a pneumatic valve manifold with support for a proportional valve. The inputs and some of the outputs can be used to control water saver valves.
|
|
 |
DN-EMU
DeviceNet Master Emulator II
The DN-EMU Emulator software application, a general-purpose tool for developing and debugging
DeviceNet nodes, comes pre-installed in DeviceGate. The
Emulator monitors DeviceNet bus traffic, accommodates time stamps, and generates
messages for configuring or testing nodes on the bus. The DN-EMU is ideal for
developers of DeviceNet products interested in testing their devices.
|
|
 |
DN-IDS16
DeviceNet 16-in Sealed Block
The DN-IDS16 is a low cost input module which allows direct connection of sensors, limit switches, or other discrete input devices to DeviceNet. This compact design provides 16 inputs via 8 standard micro-style (12mm) connectors. The sealed housing provides robust protection from harsh environments. |
|
 |
DN-PC2
DeviceNet PC Interface Card
The DN-PC2 has been discontinued and replaced by the DeviceGate. Documentation can still be found
at the link above and support is still offered. |
|
 |
DN-PROG1
Compact RS232 to 5V Serial Convertor
Perfect for programming applications, the DN-PROG1 provides a quick
conversion from RS232 to 5V serial in a compact footprint. Includes a
switch to toggle a PSEN signal and the necessary cabling to connect
directly to you laptop, the DN-PROG1 is a portable solution for
convenient code updates in the field or the lab. |
|
 |
DN-TC400 Series
DeviceNet Robot Tool Changer Modules
Huron Net Works’ DN-TC400 series products provide a low cost solution for
connecting robot tool changer applications to DeviceNet. Separate robot I/O and
tool ID boards allow for up to 256 different tools per robot. Each board
is available in two sizes and are completely interchangeable.
|
|
 |
DN-TC468
DeviceNet 68-in, 4-out 24V Discrete I/O
The DeviceNet DN-TC468 offers an unprecedented 68 general Inputs and
includes 4 Outputs all in a compact 152.4 x 88.9mm board. This module
provides the ability to control and monitor I/O points and offers
on-board and external 24 VDC auxiliary power sensing.
|
|
